HPS 0410 | Einstein for Everyone |
Back to main course page
John
D. Norton
Department of History and Philosophy of Science
University of Pittsburgh
Background reading: J. Schwartz and M. McGuinness, Einstein for Beginners. New York: Pantheon.. pp. 1 - 82.
We have now reviewed the developments in the physics of moving bodies, of light, of electricity and magnetism that brought the physics that Einstein found when he began to think about ether, electricity, magnetism and motion.
It was pondering these developments that led Einstein to discover the special theory of relativity in 1905. The discovery was not momentary. The theory was the outcome of, in Einstein's own reckoning, seven and more years of work. He even places one of his early landmarks in a thought experiment he had at the age of 16, in 1896, nine years before the year of miracles of 1905. Unfortunately we have only fragmentary sources to document the years of this struggle. Below I identify a few of the major ones.
The story of Einstein's discovery of special relativity has exercised an almost irresistible fascination on many, in spite of the dearth of sources. So, if you read more widely, you will see much speculation over how to fill in the blanks between the known landmarks and even over which are the important landmarks. Some of it is responsible; some is not.
Einstein in high school
Writing a half century later in 1946 in his Autobiographical Notes, Einstein recounted a thought experiment conducted while he was a 16 year old student in 1896 that marked his first steps towards special relativity.
"...a paradox upon which I had already hit at the age of
sixteen:
If I pursue a beam of light with the velocity c (velocity of light in a
vacuum), I should observe such a beam of light as an electromagnetic field
at rest though spatially oscillating.
There seems to be no such thing, however, neither on the basis of
experience nor according to Maxwell's equations.
From the very beginning it appeared to me intuitively clear that, judged
from the standpoint of such an observer, everything would have to happen
according to the same laws as for an observer who, relative to the earth,
was at rest. For how should the first observer know or be able to
determine, that he is in a state of fast uniform motion?
One sees in this paradox the germ of the special relativity theory is
already contained."
The basic thought is clear. If Einstein were to chase after a propagating beam of light at c
he would see a frozen light wave
and that Einstein deemed impossible.
At first it seems that is will be simple to figure out just what is worrying Einstein. He states a few simple reasons. I don't want to go into them here since they actually turn out to be rather hard to disentangle. My best effort to disentangle them is given at "Chasing the Light: Einstein's Most Famous Thought Experiment," Thought Experiments in Philosophy, Science and the Arts, eds., James Robert Brown, Mélanie Frappier and Letitia Meynell, New York: Routledge, 2013.
Einstein's thinking evolved from this early, youthful flight into richer and technically more detailed scrutiny of motion in Maxwell's electrodynamics. Einstein initially took the idea of an ether state of rest seriously and conceived experiments that were designed to reveal the earth's motion through the ether.
These thoughts eventually took a very different turn with Einstein deciding that the ether state of rest had no place in electrodynamics and that the principle of relativity was to be upheld. The decisive moment seems to have come with a thought experiment, the magnet and conductor, that is recounted in the opening paragraph of Einstein's 1905 paper.
!!!!This version of that thought experiment is modified slightly from the way Einstein sets it up. (Caution!)!!!! | The simple idea behind the thought experiment is that Maxwell's electrodynamics treats a magnet at rest in the ether very differently from one that moves in the ether. A magnet at rest is surrounded by a magnetic field only. |
However, if | through the ether, things are very different. In addition to the magnetic field, a new entity comes into being around the magnet, an induced electric field--and "E" field.The creation of the electric field draws on details of Maxwell's theory that need not distract us here. Briefly, as the magnet moves past a fixed point in the ether, the magnetic field strength changes with time at that point. That change in field strength, according to Maxwell's theory, creates an electric field. |
This difference between the two cases seems to provide an unequivocal marker of motion through the ether--or so it would seem. To determine if a magnet is moving absolutely through the ether or not, one merely needs to look for that induced electric field, E. That is easy to do. An electric field accelerates electric charges, such as the conducting electrons in a piece of wire, a conductor. So all that has to be done is to place a conductor near the magnet, as the figures show, and to look for an induced electric current. If there is one, then there is an induced electric field and the magnet is moving; if there isn't one, then the magnet is at rest in the ether.
It all seems so straightforward. But it does not work. To see why, we will look more closely at the two cases of rest and motion through the ether. The simplest situation arises if we attach the conductor to the magnet so that it moves or rests with the magnet. We might imagine the magnet-conductor assembly to be a sort of motion-through-the-ether detector.
If the magnet-conductor assembly is at rest in the ether, then there will be no current in the conductor. The ammeter that measures current will read a zero, as shown. This ammeter reading is what can be observed directly. It is how an observer can know that there is no electric field present.
So far, it is as expected. Now take the case in which the magnet-conductor assembly and the observer all move together through the ether. We might expect that the induced electric field will now act on the charges in the conductor, so that current flows in the conductor which will lead to a non-zero ammeter reading. That will not happen. In this case, an extra complication enters. Because the conductor is now moving absolutely in a magnetic field, another part of Maxwell's theory comes to bear. It tells us that when an electric charge moves in a magnetic field, there is a force--the "Lorentz force"--acting on the charge.
The Lorentz force brings about a second current in the conductor. Remarkably that second current flows in the opposite direction to the one produced by the electric field and it turns out to cancel it out exactly. That the two should balance so perfectly and cancel each other out is surely a remarkable fact. It is for ether theorists just a curiosity. For Einstein is was a decisive clue. This for him was not curious accident.
The outcome is that checking for an electric current in the conductor fails as a means of distinguishing the absolute rest of the magnet from its motion. In both cases, the current is the same--no current at all. So an Einstein riding with an absolutely moving magnet, would detect no current and find the situation to be indistinguishable from absolute rest as far as the observable currents were concerned.
The situation is striking. It is as if the electric field just isn't there for an observer moving with the magnet.
But at observer at rest in the ether would say there is an electric field present.
Einstein later described how this realization had affected him quite profoundly:
"In setting
up the special theory of relativity, the following ... idea
concerning Faraday’s magnet-electric induction [experiment] played a
guiding role for me... [magnet conductor thought experiment described]. ...The idea, however, that these were two, in principle different cases was unbearable for me. The difference between the two, I was convinced, could only be a difference in choice of viewpoint and not a real difference. Judged from the [moving] magnet, there was certainly no electric field present. Judged from the [ether state of rest], there certainly was one present. Thus the existence of the electric field was a relative one, according to the state of motion of the coordinate system used, and only the electric and magnetic field together could be ascribed a kind of objective reality, apart from the state of motion of the observer or the coordinate system. The phenomenon of magneto-electric induction compelled me to postulate the (special) principle of relativity. [Footnote] The difficulty to be overcome lay in the constancy of the velocity of light in a vacuum, which I first believed had to be given up. Only after years of [jahrelang] groping did I notice that the difficulty lay in the arbitrariness of basic kinematical concepts." |
Einstein, Albert (1920) “Fundamental Ideas and
Methods of the theory of Relativity, Presented in Their
Development,” Collected Papers of
Albert Einstein, Vol. 7, Doc. 31. Einstein in 1920 |
In sum Einstein's lesson was this. Maxwell's theory employed an ether state of rest; but that state of rest could not be revealed by observation. So somehow the principle of relativity needed to be upheld.
In retrospect, this relativity of the induced electric field had, in effect, committed Einstein to the relativity of simultaneity, although he certainly did not know it at the time. A simple thought experiment shows that it can only be reconciled with Maxwell's electrodynamics if we give up the absoluteness of simultaneity. See SEction 4.2 in "Einstein's Special Theory of Relativity and the Problems in the Electrodynamics of Moving Bodies that Led him to it." pp. 72-102 in Cambridge Companion to Einstein, M. Janssen and C. Lehner, eds., Cambridge University Press. | And a second moral was an unexpected relativity. Prior to Einstein, it had been thought that whether an electric field is present at some place is an absolute fact. Einstein now concluded that it is observer dependent: some observers will judge an electric field to be present; others in a different state of motion will not. This was the first of Einstein's reorganization of our ideas of which quantities are absolute and which relative. |
The magnet and conductor thought experiment marked the way forward for Einstein. He was to uphold the principle of relativity in electrodynamics. The immediate difficulty Einstein faced was that one of the most impressive results of Maxwell's electrodynamics. It concerned the speed of propagation of waves in the electromagnetic field. Using only results derived from experiments in electricity and magnetism, Maxwell was able to show that these waves would propagate at 186,000 miles per second. That speed coincided with the then empirically known speed of light waves. The conclusion of irresistible:
Light waves just are electromagnetic waves.
This identification of light with electromagnetic waves was one of the crowning achievements of Maxwell's theory
Attached to this extraordinary outcome was the primary obstacle Einstein now faced in his project of upholding the principle of relativity in electrodynamics: the speed of light determined by Maxwell's theory was 186,000 miles per second--c--with respect to the ether. It was never faster or slower, but always this fixed number. Light always propagated at exactly c in a vacuum with respect to the ether. That meant that observers could determine their states of motion merely by measuring whether a light ray moved at c. If it did, then they were at rest in the ether. If it did not, then they were moving in the ether.
Here is a simple way to see the problem and the solution Einstein tried. A car is at rest in the ether. It projects a light wave forward at c from its headlights.
Now if the car is set in motion at high speed in the direction of the light wave, the light wave will be unaffected by the motion of the car's headlights. It will still propagate at c with respect to the ether. That was a core result in Maxwell's theory. That means that, according to Newtonian ideas about space and time, the light will be slowed in the car's frame of reference. The principle of relativity would fail.
This failure would not arise if light propagation worked as Newton had supposed. He theorized that light consisted of little corpuscles that behaved like tossed pebbles. Someone tossing a pebble would give it some motion. If that person was also moving, that person's motion would be added to that of the pebble. If light from a car's headlights acted this way, the motion of the car would be added to that of the light:
In this Newtonian account, the light always moves at c relative to the car. Measuring the speed of the emitted light no longer allows observers in the car to make any determination of their absolute motion with respect to the ether, if there is such a thing.
Einstein now proposed that the same addition effect applies to light waves
The velocity of the emitted light is increased by whatever velocity the car may have. Once again, measuring the speed of the emitted light no longer provides a means to determine absolute motion.
What results is called an "emission" theory of light. The defining characteristic is that the velocity of the emitter is added to the velocity of the emitted light to give the final velocity of light.
Walther Ritz |
The pursuit of an emission theory was a natural
way forward. But it was only an idea. The difficulty was to
determine how to modify electrodynamical
theory so that light propagations and other related
electrodynamic effects conformed with the emission theory. This was
no easy task. Maxwell's electrodynamics was a quite complicated
theory. Its many equations were each adapted to specific
experimental results. One could not easily change one part without
producing problems in other parts. It turns out that there was a promising avenue of modification of Maxwell's theory that looked like it would bring electrodynamics into conformity with an emission theory. This avenue had been found shortly after Einstein's work of 1905 by Walther Ritz. |
Einstein later recalled that the theory he developed was essentially the one published by Ritz in 1908. In Ritz's theory--and thus probably also in Einstein's theory--all electrodynamic action, not just light, propagates in a vacuum at c with respect to the action's source. The essential change is shown in the animation: | For experts: the way to build the theory was actually quite easy. If Maxwell's theory is formulated in terms of retarded potentials, one needs only to tinker with the formula for the retardation time to bring the whole theory into the form of an emission theory. Everything else can stay the same. |
In Maxwell's theory, all electrodynamic action,
generated by a source charge at some moment, propagates at c from
the fixed point in the ether occupied
by the source at that moment.
|
In a Ritz-style emission theory, all
electrodynamic action, generated by a moving source, propagates at
c from a point that moves at uniform
velocity with the source.
|
Here is a non-animated version:
My own best effort to reconstruct of the details of Einstein's theory can be found in "Einstein's Investigations of Galilean Covariant Electrodynamics prior to 1905," Archive for History of Exact Sciences, 59 (2004), pp. 45-105.
It was a lovely theory. But it didn't work. We can only guess what the problems were. But we know that Einstein found many. Indeed Einstein seems to have expended considerable energy trying to figure out if any emission theory might work. His later recollections are littered with different reasons for why no emission theory at all could do justice to electrodynamics. | My own conjectures on how these arguments may have worked are discussed in part in my "Chasing the Light: Einstein's Most Famous Thought Experiment," Thought Experiments in Philosophy, Science and the Arts, eds., James Robert Brown, Mélanie Frappier and Letitia Meynell, New York: Routledge, 2013. |
An emission theory fails. So Einstein would have found himself in an impossible position. The speed of light cannot vary with the speed of the emitter; presumably it must be a constant, as Maxwell's theory had urged all along. Yet in addition, Einstein was convinced that the principle of relativity must obtain in electrodynamic theory. How can both obtain? They require the speed of light to be the same for all inertial observers?
The footnote already quoted above points us to Einstein's
next step.
"The difficulty to be overcome lay in the constancy of the velocity of
light in a vacuum, which I first believed had to be given up. Only after
years of [jahrelang] groping did I notice that the difficulty lay in the arbitrariness
of basic kinematical concepts."
The key to the puzzle is the relativity of simultaneity. If Einstein gives up the absoluteness of simultaneity, then the principle of relativity and the constancy of the speed of light are compatible after all. The price paid for the compatibility is that we must allow that space and time behaves rather differently than Newton told us.
More importantly for Einstein's struggles of that time is
an extra bonus: it turns out that within the new theory of space and time
of special relativity, Maxwell's electrodynamics does
not need to be modified at all. It turns out to be compatible
with principle of relativity just as it is. That would have been a very
satisfactory outcome for Einstein.
Einstein recounted later the moment of discovery. In a lecture in Kyoto on December 14, 1922, he is reported by Ishiwara, who took notes in Japanese, to have said:
"Why are these two things inconsistent with each
other? I felt that I was facing an extremely difficult problem. I
suspected that Lorentz’s ideas had to be modified somehow, but spent
almost a year on fruitless thoughts. And I felt that was puzzle not
to be easily solved. But a friend of mine living in living in Bern (Switzerland) [Michele Besso]helped me by chance. One beautiful day, I visited him and said to him: ‘I presently have a problem that I have been totally unable to solve. Today I have brought this “struggle” with me.’ We then had extensive discussions, and suddenly I realized the solution. The very next day, I visited him again and immediately said to him: ‘Thanks to you, I have completely solved my problem.” My solution actually concerned the concept of time. Namely, time cannot be absolutely defined by itself, and there is an unbreakable connection between time and signal velocity. Using this idea, I could now resolve the great difficulty that I previously felt. After I had this inspiration, it took only five weeks to complete what is now known as the special theory of relativity." Translation from Stachel, John (2002) Einstein from ‘B’ to ‘Z.’: Einstein Studies, Volume 9. Boston: Birkhäuser, p. 185. |
Einstein taking sake A portrait of Einstein by the cartoonist Okamoto Ippei (1886-1948), done in December of 1922 in Sendai, Miyagi Prefecture, Japan |
David Hume |
This moment of recognition of the relativity of simultaneity is one of the great moments of discovery in science and, at this moment philosophical reflections played a key role. Absolute simultaneity seems an uncontroversial part of the world. How could we give it up? Einstein had been reading many philosophers, including Hume and Mach. They had stressed that concepts are our servants, not our masters, and they are warranted only in so far as they might be grounded in experience. So was absolute simultaneity grounded properly in experience? Einstein began to think about the experiences that we use to establish simultaneity of events and he realized that it was not. Reading these philosophers gave him the courage to continue and to abandon absolute simultaneity. In its place came the relativity of simultaneity. | Ernst Mach |
For an account of how reading Hume and Mach helped, see my "How Hume and Mach Helped Einstein Find Special Relativity."
The moment of the recognition of the relativity of simultaneity came, in the above account, 5 weeks prior to Einstein's completion of the 1905 paper (and in another 5 to 6 weeks). In these five to six weeks in which he pulled together the pieces of the finished theory, Einstein made one more very significant methodological advance that would forever color how we see relativity theory.
Einstein's pathway to discovery amounted to the recognition that if you take Maxwell's electrodynamics seriously you have to see that built into it is both the principle of relativity and a new kinematics of space and time that supports it. Yet Einstein does not simply argue it that way in the finished paper.
The reason is not hard to see. Prior to, just a few months before completing his 1905 special relativity paper, Einstein had published a paper in which he had foreshadowed the demise of Maxwell's electrodynamics! In his earlier light quantum, Einstein had advanced the astonishing assertion that sometimes light does not behave like a wave as Maxwell's theory demanded; sometimes it behaved like a spatially localized collection of energy. |
So how could Einstein now base a new theory of space and time on Maxwell's theory? He knew something was very right about Maxwell's theory. There was also something very wrong about it. How could one theorize in such an unstable environment. The answer came to Einstein, as he reported in his Autobiographical Notes, in a distinction of what he called constructive theory from theories of principle.
"Reflections of this type made it clear to me as long ago as shortly after 1900, i.e., shortly after Planck's trailblazing work, that neither mechanics nor electrodynamics could (except in limiting cases) claim exact validity. Gradually I despaired of the possibility of discovering the true laws by means of constructive efforts based on known facts. The longer and the more desperately I tried, the more I came to the conviction that only the discovery of a universal formal principle could lead us to assured results. The example I saw before me was thermodynamics. The general principle was there given in the theorem: The laws of nature are such that it is impossible to construct a perpetuum mobile (of the first and second kind). How, then, could such a universal principle be found?"
In effect, what Einstein saw was that he did not really need all of Maxwell's theory for his new account of space and time. He needed only a few core ideas robust enough to survive the coming quantum revolution. Following the model of thermodynamics, these few core ideas would be advanced as principles from which the entire theory could be deduced.
What could those principles be? The principle of relativity itself was an obvious choice. He also needed something that distilled the relevant essence of Maxwell's electrodynamics. What about the hardest won lesson of his years of work towards the final theory: the recognition that an emission theory of light must fail? That is, that Maxwell's theory was right after all in demanding that that light always propagates at c, no matter how fast the emitter may be moving? That became the second principle, the light postulate. Those two principles proved to be sufficient to allow the entire theory to be deduced. Einstein laid out both as his postulates and the theory adopted its now familiar form.
We have seen three components in Einstein's discovery:
While all three had a role in Einstein's discovery, the last was the most decisive. Unfortunately this is often overlooked in accounts of the origins of Einstein's theory. Einstein's engagement with current experiments and his facility in philosophical analysis are important. However special relativity would not have come about at all were it not for the particular problems in electrodynamics addressed by Einstein and which demanded a radical solution.
Einstein arrived at his "On the electrodynamics of moving bodies," which is my best candidate for the most famous scientific paper ever written. | An online version of this paper is here. Beware of a famous misrendering in this standard edition as noted in this version of the first two sections. |
The paper has several parts. First there is an introduction. It commences with the recounting of the magnet and conductor thought experiment. It then announces the project of solving the resulting problem with a new theory of space and time based on the principle of relativity and the light postulate.
In the first "Kinematical Part" of the paper, Einstein develops the parts of the theory devoted only to space and time. Its first section, "Definition of Simultaneity," Einstein gives his celebrated analysis of the relativity of simultaneity. It is one of the most celebrated conceptual analyses of the century and a model very many others tried to follow. |
The second "Electrodynamical
Part" proceeds to what must have seemed for Einstein in
1905 to be the real benefit of the paper. He proceeded to show how
Maxwell's electrodynamics was already a theory that conformed to the
principle of relativity and noted that this fact made solution of
some problems in electrodynamics very easy. For a problem concerning moving systems, such as the reflection of light off a moving mirror, was really the same as another much easier problem with resting bodies, such as the reflection of light off a resting mirror. If you could solve the easy problem, then the principle of relativity let you write down a solution to the harder one almost immediately, just by transforming your viewpoint from one frame of reference to another. |
For more on Einstein's discoveries of 1905, see my website.
Copyright John D. Norton. January 2001, September 2002; July 2006; January 2, 2007; January 21,February 4, 2008; January 15, 2010. September 11, 2020. Jnauary 22, 2022. Links updated January 23, 2024.
